TS-233
| Operating System |
QTS 5.1.3 |
| Supported Client Operating Systems |
|
| Supported Browsers |
|
| Supported Languages |
Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, and Turkish |
| Storage Pool |
|
| SED Storage Pool |
|
| Maximum Pool size |
308 TB |
| Maximum number of storage pool |
128 |
| Volume Type |
Thick, Thin, Static |
| Maximum volume size |
250 TB |
| Maximum number of volume |
128 |
| Maximum shared folder size |
250 TB |
| Maximum number of shared folder |
512 |
| JBOD Expansion |
|
| VJBOD / VJBOD Cloud |
|
| iSCSI Service |
|
| Fibre Channel Service |
|
| LUN Type |
Thick, Thin |
| File-based iSCSI LUN |
|
| Block-based iSCSI LUN |
|
| Maximum LUN size |
250 TB Note: At least 4 GB RAM is required. |
| Maximum number of targets LUN |
128 |
| LUN feature |
|
| Auto Tiering |
|
| RAID Type |
|
| RAID Group |
|
| RAID Level Migration |
|
| RAID Expansion (by adding Disk) |
|
| RAID Expansion (by replacing bigger Disks) |
|
| Storage Pool Expansion (by adding RAID Group) |
|
| RAID Hot Spare |
Global, Local |
| RAID Sync/Rebuild/Scrubbing |
|
| Internal drive |
EXT4 |
| External drive |
EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT (optional for ARM model) |
| Disk, Enclosure Locate |
|
| Disk S.M.A.R.T. Scan |
|
| Disk S.M.A.R.T. Data Migration |
|
| Ironwolf Health Management |
|
| Secure Erase |
|
| SSD Trim |
|
| SSD Life Estimation |
|
| Disk Roaming |
|
| Disk Standby |
|
| Volume Snapshot |
|
| LUN Snapshot |
|
| Maximum Snapshot (Per System) | |
| Maximum Snapshot (Per Volume / LUN) | |
| Minimum Snapshot Interval |
5 minutes |
| Snapshot Retention Policy |
|
| Self-serve Snapshot Recovery |
|
| Application Consisted Snapshot |
|
| Snapshot Full Clone |
|
| Snapshot Replica / Vault |
|
| SSD profiling tool |
|
| External Device Management |
|
| Mount Smart Phone (MTP) |
|
| External RAID Device (QNAP so on) Management (External Device Mode) |
|
| External RAID Device (QNAP so on) Management (NAS Mode) |
|
| File Server |
|
| FTP Server |
|
| Maximum FTP connection |
1024 |
| File Station (Web) |
|
| Object Storage |
|
| Local user account |
4,096 |
| Local group account |
512 |
| Domain user/group account |
200,000 |
| Domain Security |
|
| Domain Controller |
|
| Shared folder permission |
|
| Advanced folder permission |
|
| Windows ACL |
|
| User quota |
|
| Group quota |
|
| Folder quota |
|
| Home folder |
|
| Resource Monitor |
|
| SNMP |
V2, V3 |
| Network recycle bin |
|
| System Log & Notification Center |
Log recording: 3,000 event per second |
| Smart Fan |
|
| Schedule on/off |
|
| Internet protocol |
IPv4, IPv6 |
| Virtual Switch |
|
| Port trunking |
|
| VLAN |
|
| DHCP Server |
|
| DDNS (Dynamic Domain Name Service) |
|
| Network access protection with auto-blocking |
SSH, Telnet, HTTP(S), FTP, CIFS/SMB, and AFP |
| Security Counselor |
|
| Malware Remover |
|
| AES 256-bit Volume Encryption validated by FIPS 140-2 CAVP |
|
| 2-step verification |
|
| Allow/Deny List |
|
| Access Protection |
|
| Service binding |
|
| Firewall |
|
| vSphere Web Client Plug-in |
|
| VMware vSphere VAAI for iSCSI |
|
| VMware vSphere VAAI for NAS |
|
| Windows ODX |
|
| Windows/VMware Snapshot Agent |
|
| HTTP/HTTPS Connections |
TLS 1.0/1.1/1.2/1.3 |
| Supports WebDAV Connection |
|
| Supports Virtual Hosts |
32 |
| Qsync |
Note: At least 1 GB RAM is required. |
| [Qsync] Management Mode |
User customization, Central |
| [Qsync] Qsync client supported platforms |
Windows, macOS, Ubuntu, Android, and iOS |
| [Qsync] Maximum number of version control |
64 |
| HybridMount |
|
| [HybridMount] File Cloud Gateway |
Concurrent Connections = 20 Upload & 20 Download |
| [HybridMount] Network Drive Mount |
|
| [HybridMount] Free cloud gateway sessions |
2 |
| HBS (Hybrid Backup Sync) |
|
| [HBS (Hybrid Backup Sync)] NAS to NAS backup |
|
| [HBS (Hybrid Backup Sync)] Cloud Backup |
|
| [HBS (Hybrid Backup Sync)] Cloud Sync |
|
| [HBS (Hybrid Backup Sync)] 2-way and Active Sync |
|
| [HBS (Hybrid Backup Sync)] Apple Time Machine Backup |
|
| [HBS (Hybrid Backup Sync)] External drive backup |
|
| [HBS (Hybrid Backup Sync)] Maximum number of backup job |
400 |
| Qsirch |
|
| [Qsirch] Previews |
Photos, music, videos, PDFs, Gmail, and others |
| [Qsirch] Integrate Mac Finder |
|
| [Qsirch] Advanced picture search |
|
| [Qsirch] Search filters |
|
| QuMagie |
|
| [QuMagie] Browse photos |
|
| [QuMagie] Virtual and smart albums |
|
| [QuMagie] AI-assisted photo management |
People, things, places, and others |
| Antivirus (free) |
|
| QVPN Service |
|
| [QVPN Service] Remote Access |
PPTP, L2TP/IPSec, OpenVPN, QBelt (QNAP proprietary) |
| [QVPN Service] Supportedd utility and mobile app |
Windows, macOS, iOS, and Android |
| [QVPN Service] Supported maximum clients |
100 |
| LDAP Server |
|
| RADIUS |
|
| SQL server |
|
| License Center |
|
| Multimedia Console |
|
| Photo Station |
|
| Music Station |
|
| Video Station |
|
| Download Station |
|
| Notes Station |
|
| Qfiling |
|
| Media Streaming add-on |
|
| QmailAgent |
|
| QuWAN |
|
| DA Driver Analyzer |
|
| Q'center |
|
| Q'center Server |
|
| Q'center Agent |
|
| Connect to Q'center |
|
| Container Station |
|
| [Container Station] Supported type |
LXC/LXD and Docker |
| [Container Station] Docker Hub Registry |
|
| [Container Station] Container importing and exporting |
|
| [Container Station] Console mode |
|
| QVR Elite |
|
| [QVR Elite] Recording Technique |
Standard MP4 file based |
| [QVR Elite] License Type |
Subscription-based |
| [QVR Elite] User-defined trigger events |
|
| [QVR Elite] QVR Pro Client (Desktop) |
Windows, macOS, and QNAP HybridDesk Station |
| [QVR Elite] QVR Pro Client (Mobile) |
Android and iOS |
| [QVR Elite] Recording camera streams |
H.264 |
| [QVR Elite] Free built-in camera channels |
2 |
| QVR Pro Client |
|
| [QVR Pro Client] Dynamic View Layout |
|
| [QVR Pro Client] Windows |
|
| [QVR Pro Client] Mac |
|
| [QVR Pro Client] HybridDesktop |
|
| [QVR Pro Client] iOS |
|
| [QVR Pro Client] Android |
|
| QVR Human |
|
| QVR Face |
|
| QVR DoorAccess |
|
TS-233
| CPU | ARM 4-core Cortex-A55 2.0GHz processor |
| CPU Architecture | 64-bit ARM |
| Floating Point Unit |  |
| Encryption Engine | |
| Neural Processing Unit (NPU) | |
| System Memory | 2 GB on board (non-expandable) |
| Maximum Memory | 2 GB on board (non-expandable) |
| Flash Memory | 4 GB (Dual boot OS protection) |
| Drive Bay | 2 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | |
| Gigabit Ethernet Port (RJ45) | 1 |
| Wake on LAN (WOL) | |
| Jumbo Frame | |
| USB 2.0 port | 2 |
| USB 3.2 Gen 1 port | 1 |
| Form Factor | Tower |
| LED Indicators | System Status, LAN, USB, HDD1~2 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 186 × 91.7 × 157.6 mm |
| Weight (Net) | 1.69 kg |
| Weight (Gross) | 1.89 kg |
| Operating temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27?C (80.6?F) |
| Power Supply Unit | Minimum 48W adapter (12VDC), 100-240VAC |
| Power Consumption: HDD Sleep Mode | 3.43 W |
| Power Consumption: Operating Mode, Typical | 10.81 W |
| Fan | 1 x 80mm, 12VDC |
| System Warning | Buzzer |
| Standard Warranty | 2 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 200 |
TS-233
AC Adapter
Power Cord
